ProTouch Retrofit Solution
—High-performance IR touch frames for any display type
Product Advantages
±1mm precision
High‑accuracy touch for professional DIY projects – responsive and reliable.
10‑40 touch points
From 10 to 40 simultaneous touches, depending on series. Perfect for collaborative applications.
Plug & Play
Windows, macOS (multi‑touch driver), Linux, Android. No drivers needed for basic HID.
TUIO & SDK
Full SDK and TUIO protocol for deep integration into custom software.
One frame for endless DIY projects
Whatever you build — we have the touch core
Whether you are DIYing a kiosk, digital signage, interactive whiteboard, advertising display, information terminal, large classroom LED screen, conference room command center, or any high‑end touch PC — Touchsmith provides standard & custom size IR touch frames with premium performance.
All you need is a Touchsmith frame: choose from E‑Series (up to 500″), K‑Series (ultra‑slim for LED), or F‑Series (27‑110″). We deliver the touch component — you create the masterpiece.
* Custom sizes available upon request. Each series supports the full range of applications listed above.
DIY component series
Technical specifications
E‑Series · custom up to 500"
| Accuracy | < ±1mm |
| Touch points | 10–32 simultaneous |
| Response | <10ms |
| Max size | 500″ (12m) |
| Sunlight | 10k LUX, shielded |
| Architecture | Modular PCBA, QC-SUSB |
| Compatibility | Win/macOS/Linux/Android, TUIO |
Ideal for DIY
K‑Series · slim 12mm, up to 240"
| Accuracy | < ±1mm |
| Touch points | 20 simultaneous |
| Response | <6ms |
| Max size | 240″ (5m) |
| Bezel | 12mm (world’s narrowest) |
| Dual-host | Dual-USB, dynamic mapping |
| Anti-interference | LED noise filtering |
Ideal for DIY
F‑Series · 27–110", 40‑touch
| Accuracy | < ±1mm |
| Touch points | 40-touch capability |
| Latency | <10ms |
| Sunlight | 10klux operation |
| Profile/Bezel | 10mm thin, 18mm bezel |
| Reliability | 500k+ units deployed |
| Glass overlay | 3mm tempered (optional) |
Ideal for DIY
